BF-S2eVM1 Smart Temperature Controller–BiFang Series

BF-S2eVM1 Smart Temperature Controller–BiFang Series

Product details Downlaod

Housing material:

PC ABS

Dimensions:

Front 32x74 mm; depth 60mm;

Installation size:

Fixed on a panel with a hole of 71x29 mm;

Overall protection level:

IP65;

Front panel protection level:

IP67;

Terminals:

IDC RAST 2.5mm Puncture Connector 2P *1

IDC RAST 2.5mm Puncture Connector 4P *2

IDC RAST 2.5mm Puncture Connector 6P *1

250 spring terminal*6

Power supply:

According to the Model, there are: 90-240Vac ±10%, 50/60Hz. Please refer to the real brand;

power consumption:

Maximum 3VA;

Display:

3-digit white digital tube, 43mm×16mm×6mm

Input:

Up to 3 channels NTC inputs

Digital input:

Passive switch quantity

Output relay:

Compressor: SPST 16(6)A 250Vac

Melting frost:

SPDT 8(3) A, 250Vac

Evaporator fan:

SPST 5(2) A

Data storage:

4M flash

Maximum insulation voltage:

2500V;

Maximum input current:

5A

Operating temperature:

-30℃~55℃

Storage temperature:

-40℃~80℃

Relative humidity:

5~90RH% (no condensation)

Measure and control the temperature range:

NTC -40~110°C;

Resolution:

0.1 °C or 1 °C;

Accuracy (at ambient temperature 25°C):

±0.3 °C ±1 bit
